Gehl

Showing all 6 results

•

  Gehl R105

  Engine Model	Yanmar -Tier IV
  Travel speed	5.9 mph
  Operating Weight	4,000 lbs.
  Gross Power @ 2500 rpm	34.7 hp
  Rated Operating Capacity	1,050 lbs.

  Dimensions

  Overall Operating Height – Fully Raised	139.6″
  Height to Hinge Pin – Fully Raised	107.5″
  Overall Height to Top of ROPS	70.3″
  Overall Length with Bucket	114″
  Dump Angle at Full Height	42°
  Dump Height	84.5″
  Dump Reach at Full Height	22.8″
  Rollback at Ground	29°
  Rollback Angle at Full Height	99°
  Seat to Ground Height	32.6″
  Wheelbase	34.5″
  Overall Width – Less Bucket A	48.4″
  Bucket Width	55″
  Ground Clearance to Chassis	6.0″
  Overall Length – Less Bucket	88.9″
  Departure Angle	26°
  Clearance Circle – Front w/ Bucket	69.4″
  Clearance Circle – Front w/o Bucket	44.1″
  Clearance Circle – Rear	54.1″
  Standard Specification Tire Size	27×8.5×15 HD

  Engine

  Make	Yanmar
  Model	3TNV88C-KMS Tier IV
  Gross Power @ 2500 rpm	34.7 hp
  Net Power @ 2500 rpm	33.1 hp
  Maximum Torque	80.7 ft.-lbs. @ 1820
  Displacement	100 cu.in.

  Hydraulic System

  Auxiliary Hydraulics – Standard	14.5 gpm
  High-Flow Auxiliary Hydraulics – Option	N/A
  Reservoir Capacity	8 gal.

  Electrical System

  Battery	12-volt
  Starter	12-volt
  Alternator	40-amp

  Electrical System

  Rated Operating CapacityB	1,050 lbs.
  Rated Operating Capacity with Optional CounterweightB	1,175 lbs.
  Fuel Tank	10.4 gal.
  Travel Speed – Maximum	5.9 mph
  Travel Speed with Two-Speed Option – Maximum	N/A
  Operating WeightC – Approximate	4,000 lbs.



  A – Overall width is dependent upon the amount of wheel offset.

  B – Per SAE J818, SAE J732, and ISO 14397

  C – Weight of base unit with standard equipment, standard tires (heavy-duty flotation), standard dirt-construction bucket and 79 kg operator.



  Highlights:

  • A full line of Edge attachments and accessories are designed specifically to fill operators’ needs, making their R105 the most versatile machine on the job site.
  • The R105 provides 14.5 gpm (55) of hydraulic flow powering a variety of attachments to get work done faster.
  • Ergonomic controls in the R105 Skid Loader provide smooth loader and attachment operation.
•

  Gehl R135

  Engine Model	Yanmar -Tier IV
  Travel speed	8.0 mph
  Operating Weight	5,130 lbs.
  Gross Power	46.3 hp
  Rated Operating Capacity	1,350 lbs.

  Dimensions

  Overall Operating Height – Fully Raised	143.9″
  Height to Hinge Pin – Fully Raised	109.6″
  Overall Height to Top of ROPS	75.1″
  Overall Length with Bucket	120.3″
  Dump Angle at Full Height	40°
  Dump Height	82.6″
  Dump Reach at Full Height	22.7″
  Rollback at Ground	29°
  Rollback Angle at Full Height	82°
  Seat to Ground Height	33.3″
  Wheelbase	37.6″
  Overall Width – Less Bucket A	52.6″
  Bucket Width	54″
  Ground Clearance to Chassis	7.9″
  Overall Length – Less Bucket	92.2″
  Departure Angle	25°
  Clearance Circle – Front w/ Bucket	72.5″
  Clearance Circle – Front w/o Bucket	44.1″
  Clearance Circle – Rear	54″
  Standard Specification Tire Size	10.00 x 16.5 HD

  Engine

  Make	Yanmar
  Model	4TNV88C-KMS Tier IV
  Gross Power @ 2500 rpm	46.6 hp
  Net Power @ 2500 rpm	44.5 hp
  Maximum Torque	107.8 ft.-lbs. @ 1820
  Displacement	133.6 cu.in.

  Hydraulic System

  Auxiliary Hydraulics – Standard	17 gpm
  High-Flow Auxiliary Hydraulics – Option	N/A
  Reservoir Capacity	10 gal.

  Electrical System

  Battery	12-volt
  Starter	12-volt
  Alternator	100-amp

  Capacities/Weights

  Rated Operating CapacityB	1,350 lbs.
  Rated Operating Capacity with Optional CounterweightB	1,500 lbs.
  Fuel Tank	16.5 gal.
  Travel Speed – Maximum	8.0 mph
  Travel Speed with Two-Speed Option – Maximum	N/A
  Operating WeightC – Approximate	5,130 lbs.

  A – Overall width is dependent upon the amount of wheel offset.

  B – Per SAE J818, SAE J732, and ISO 14397

  C – Weight of base unit with standard equipment, standard tires (heavy-duty flotation), standard dirt-construction bucket and 79 kg operator.

  Highlights:

  • The R135 has amped-up hydraulic systems which incorporate intuitive design for precise controllability.
  • The R135 Operator’s cabin features a new, state-of-the-art, fully-adjustable operator’s cab.
  • The R135 is equipped with an all-new Yanmar Tier IV naturally-aspirated diesel engine.
•

  Gehl R150

  Engine Model	Yanmar -Tier IV
  Travel speed	7.4 mph
  Operating Weight	5,930 lbs.
  Gross Power	46.6 hp
  Rated Operating Capacity	1,500 lbs.

  Dimensions

  Overall Operating Height – Fully Raised	152.6″
  Height to Hinge Pin – Fully Raised	118.8″
  Overall Height to Top of ROPS	76.7″
  Overall Length with Bucket	122.1″
  Dump Angle at Full Height	38°
  Dump Height	93.7″
  Dump Reach at Full Height	22.8″
  Rollback at Ground	28°
  Rollback Angle at Full Height	99°
  Seat to Ground Height	35.6″
  Wheelbase	38.9″
  Overall Width – Less Bucket A	63.2″
  Bucket Width	61.5″
  Ground Clearance to Chassis	6.3″
  Overall Length – Less Bucket	93.9″
  Departure Angle	21°
  Clearance Circle – Front w/ Bucket	73.6″
  Clearance Circle – Front w/o Bucket	45.4″
  Clearance Circle – Rear	57.7″
  Standard Specification Tire Size	10.00 x 16.5 HD

  Engine

  Make	Yanmar
  Model	4TNV88C-KMS Tier IV
  Gross Power @ 2500 rpm	46.6 hp
  Net Power @ 2500 rpm	44.5 hp
  Maximum Torque	107.8 ft.-lbs. @ 1820
  Displacement	133.6 cu.in.

  Hydraulic System

  Auxiliary Hydraulics – Standard	17 gpm
  High-Flow Auxiliary Hydraulics – Option	N/A
  Reservoir Capacity	11 gal.

  Electrical System

  Battery	12-volt
  Starter	12-volt
  Alternator	100-amp

  Capacities/Weights

  Rated Operating CapacityB	1,500 lbs.
  Rated Operating Capacity with Optional CounterweightB	1,650 lbs.
  Fuel Tank	16.5 gal.
  Travel Speed – Maximum	7.4 mph
  Travel Speed with Two-Speed Option – Maximum	N/A
  Operating WeightC – Approximate	5,930 lbs.

  A – Overall width is dependent upon the amount of wheel offset.

  B – Per SAE J818, SAE J732, and ISO 14397

  C – Weight of base unit with standard equipment, standard tires (heavy-duty flotation), standard dirt-construction bucket and 175 lb. operator.

  Highlights:

  • The Gehl R150 has amped-up hydraulic systems which incorporate intuitive design for precise controllability.
  • Its Operator’s cabin features a new, state-of-the-art, fully-adjustable operator’s cab.
  • It is equipped with an all-new Yanmar Tier IV naturally-aspirated diesel engine.
•

  Gehl R165

  Engine Model	Yanmar -Tier IV
  Travel speed	7.8 mph
  Operating Weight	6165 lbs.
  Gross Power	69.3 hp
  Rated Operating Capacity	1,650 lbs.

  Dimensions

  Overall Operating Height – Fully Raised	152.6″
  Height to Hinge Pin – Fully Raised	118.8″
  Overall Height to Top of ROPS	76.7″
  Overall Length with Bucket	122.1″
  Dump Angle at Full Height	38°
  Dump Height	93.7″
  Dump Reach at Full Height	22.8″
  Rollback at Ground	28°
  Rollback Angle at Full Height	99°
  Seat to Ground Height	35.6″
  Wheelbase	38.9″
  Overall Width – Less Bucket A	63.2″
  Bucket Width	61.5″
  Ground Clearance to Chassis	6.3″
  Overall Length – Less Bucket	93.9″
  Departure Angle	21°
  Clearance Circle – Front w/ Bucket	73.6″
  Clearance Circle – Front w/o Bucket	45.4″
  Clearance Circle – Rear	57.7″
  Standard Specification Tire Size	10.00 x 16.5 HD

  Engine

  Make	Yanmar
  Model	4TNV98C-NMS2 Tier IV
  Gross Power @ 2500 rpm	69.3 hp
  Net Power @ 2500 rpm	68.4 hp
  Maximum Torque	178 ft.-lbs. @ 1625
  Displacement	201.4 cu.in.

  Hydraulic System

  Auxiliary Hydraulics – Standard	18.9 GPM
  High-Flow Auxiliary Hydraulics – Option	Available
  Reservoir Capacity	11 gal.

  Electrical System

  Battery	12-volt
  Starter	12-volt
  Alternator	100-amp

  Capacities/Weights

  Rated Operating CapacityB	1,650 lbs.
  Rated Operating Capacity with Optional CounterweightB	1,800 lbs.
  Fuel Tank	16.5 gal.
  Travel Speed – Maximum	7.8 mph
  Travel Speed with Two-Speed Option – Maximum	N/A
  Operating weight – Approximate	6,165 lbs.

  A – Overall width is dependent upon the amount of wheel offset.

  B – Per SAE J818, SAE J732, and ISO 14397

  C – Weight of base unit with standard equipment, standard tires (heavy-duty flotation), standard dirt-construction bucket and 175 lb. operator.

  Highlights:

  • The Gehl R165 rounds up the mid-frame skid loader class with top-notch performance.
  • The R135 Operator’s cabin features a new, state-of-the-art, fully-adjustable operator’s cab.
  • The R165 has amped-up hydraulic systems that incorporate intuitive design for precise controllability.
•

  Gehl R190

  Engine Model	Yanmar – Tier IV/Stage 3B
  Travel speed	7.5 mph
  Operating Weight	6,880 lbs
  Gross Power @ 2500 rpm	69.3 hp
  Overall Operating Height	158″

  Dimensions

  Overall Operating Height – Fully Raised	158″
  Height to Hinge Pin – Fully Raised	120.5″
  Overall Height to Top of ROPS	80″
  Ground Clearance to Chassis	6.5″
  Overall Length with Bucket	127″ with 66″ Bucket
  Overall Length without Bucket	94″
  Wheelbase	42″
  Dump Reach – Fully Raised	22.5″
  Rollback at Ground	26°
  Dump Angle	42°
  Overall Width	66.5″/64.5″A
  Bucket Width	66″
  Clearance Circle – Rear	58.5″
  Clearance Circle – Front without Bucket	44.5″
  Clearance Circle – Front with Bucket	79″
  Seat to Ground Height	39″
  Rollback at Specified Height	96°
  Dump Height	91″
  Departure Angle	25°
  Standard Specification Tire Size	10.00 x 16.5 HD

  Engine

  Make	Yanmar
  Model	4TNV98C-NMS Tier IV/Stage 3B
  Gross Power @ 2500 rpm	69.3 hp
  Net Power @ 2500 rpm	68.4 hp
  Maximum Torque	173 ft.-lbs @ 1625
  Displacement	202.6 cu.in.

  Hydraulic System

  Auxiliary Hydraulics – Standard	18.5 gpm
  High-Flow Auxiliary Hydraulics – Option (L/min)	31.5 gpm
  Reservoir Capacity (L)	8 gal.

  Electrical System

  Battery	12-volt
  Starter	12-volt
  Alternator	95-amp



  Electrical System

  Rated Operating CapacityB	1,900 lbs.
  Rated Operating Capacity with Optional CounterweightB	2,110 lbs.
  Fuel Tank	16.5 gal.
  Travel Speed – Maximum	7.5 mph
  Travel Speed with Two-Speed Option – Maximum	12.5 mph
  Operating WeightC – Approximate	6,880 lbs.



  Highlights:

  • The Gehl R190 Skid Steer Loader has a spacious operator station with plenty of adjustabilities and enhanced comfort features that users have come to expect from Gehl.
  • It also has amped-up hydraulic systems that incorporate intuitive design for precise controllability.
  • Gehl R190 has taken performance to the next level of Skid Loaders.
•

  Gehl R220

  Engine     Model	Yanmar – NMS Tier IV/Stage 3B
  Travel speed	8.0 mph
  Operating Weight	7,980 lbs.
  Gross Power @ 2500 rpm	72 hp
  Overall Operating Height – Fully Raised	161″

  Dimensions

  Overall Operating Height – Fully Raised	161″
  Height to Hinge Pin – Fully Raised	123″
  Overall Height to Top of ROPS	81″
  Ground Clearance to Chassis	8″
  Overall Length with Bucket	136.5″ with 70″ Bucket
  Overall Length without Bucket	105″
  Wheelbase	43″
  Dump Reach – Fully Raised	27″
  Rollback at Ground	28°
  Dump Angle	40°
  Overall Width	69.5″/65.5″A
  Bucket Width	70″
  Clearance Circle – Rear	60″
  Clearance Circle – Front without Bucket	52″
  Clearance Circle – Front with Bucket	87.5″
  Seat to Ground Height	40″
  Rollback at Specified Height	95°
  Dump Height	94″
  Departure Angle	25°
  Standard Specification Tire Size	12.00 x 16.5 HD

  Engine

  Make	Yanmar
  Model	4TNV98CT-NMS Tier IV/Stage 3B
  Gross Power @ 2500 rpm	72 hp
  Net Power @ 2500 rpm	70.7 hp
  Maximum Torque @ rpm	217 ft.-lbs. @ 1625
  Displacement	202.6 cu.in.

  Hydraulic System

  Auxiliary Hydraulics – Standard	23.5 gpm
  High-Flow Auxiliary Hydraulics – Option	35 gpm
  Reservoir Capacity	8 gal.

  Electrical System

  Battery	12-volt
  Starter	12-volt
  Alternator	95-amp

  Capacities/Weights

  Rated Operating CapacityB	2,200 lbs.
  Rated Operating Capacity with Optional CounterweightB	2,370 lbs.
  Fuel Tank	18 gal.
  Travel Speed – Maximum	8.0 mph
  Travel Speed with Two-Speed Option – Maximum	11.9 mph
  Operating WeightC – Approximate	7,980 lbs.

  A – Narrow width with off-set wheel option

  B – Per SAE J818, SAE J732, and ISO 14397

  C – Weight of base unit with standard equipment, standard tires (heavy-duty flotation), standard dirt-construction bucket and 175 lb. operator.

  Highlights:

  • The new R220 has a spacious operator station with plenty of adjustability and enhanced comfort features that users have come to expect from Gehl.
  • The R220 has amped-up hydraulic systems which incorporate intuitive design for precise controllability.
  • The R220 is built with a robust, radial lift arm that incorporates performance and durability.
