Description
| Engine Model |
Yanmar 4TNV88 |
| Travel speed | 6.6 mph |
| Operating Weight | 4,850 lbs |
| Gross Power | 48.8 hp |
| Rated Operating Capacity | 1,350 lbs |
Dimensions
| Overall Operating Height – Fully Raised |
3,584 mm (141.1″)
|
| Height to Hinge Pin – Fully Raised | 2,794 mm (110″) |
| Overall Height to Top of ROPS |
1,826 mm (71.9″)
|
| Overall Length with Bucket |
2,952 mm (116.2″)
|
| Dump Angle at Full Height | 42° |
| Dump Height |
2,197 mm (86.5″)
|
| Dump Reach at Full Height | 528 mm (20.8″) |
| Rollback at Ground | 29° |
| Rollback Angle at Full Height | 99° |
| Seat to Ground Height | 853 mm (33.6″) |
| Wheelbase | 932 mm (36.7″) |
| Overall Width – Less Bucket | 1,346 mm (53″) |
| Bucket Width | 1,562 mm (61″) |
| Ground Clearance to Chassis | 211 mm (8.3″) |
| Overall Length – Less Bucket |
2,314 mm (91.1″)
|
| Departure Angle | 29° |
| Clearance Circle – Front w/ Bucket |
1,758 mm (69.2″)
|
| Clearance Circle – Front w/o Bucket |
1,102 mm (43.4″)
|
| Clearance Circle – Rear |
1,484 mm (58.4″)
|
| Standard Tire Size | 10.00×16.5 HD |
Engine
| Make | Yanmar |
| Model | 4TNV88 |
| Gross Power @ 2,600 rpm |
48.8 hp (36.4 kW)
|
| Net Power @ 2,600 rpm |
— (typically ~44 hp)
|
| Maximum Torque @ rpm |
142 Nm @ 1,600 rpm (105 ft‑lb)
|
| Displacement |
2.2 L (134 cu in.)
|
Hydraulic System
| Auxiliary Hydraulics – Standard |
62 L/min (16.4 gpm)
|
| High-Flow Auxiliary Hydraulics – Option | N/A |
| Reservoir Capacity | 30 L (8 gal) |
Electrical System
| Battery | 12 V (720 CCA) |
| Starter | 12 V (3 kW) |
| Alternator | 55 A |
Capacities/Weights
| Rated Operating Capacity |
612 kg (1,340 lb)
|
| Fuel Tank | 47 L (12.4 gal) |
| Travel Speed – Maximum |
10.7 km/h (6.6 mph)
|
| Operating Weight – Approximate |
2,200 kg (4,601–4,850 lb)
|
