MT-X 625

The MT-X 625 H handler is the perfect machine for construction work involving lower heights: placing pallets, taking on bulks, unloading operations, etc. The compact dimensions of this unit make it perfect for cramped sites, and with its 4-wheel drive and steering you can easily get around, even on cluttered terrain. To ensure optimum working comfort, the MT-X 625 H is equipped with an ergonomic driver’s seat which gives you quick and easy access to all of the information you need. Thanks to the JSM (Joystick Switch & Move) system, controls can be handled with just the one hand, meaning you remain in full control of your handler at all times for increased productivity. A truly versatile machine, a number of interchangeable attachments are available to meet all of your on-site needs.

Product Description

Lifting height 5.85 m 19’2″
Lifting capacity 2500 kg 5500 lb
Weight (unladen) 4710 kg 10362 lb
Engine Kubota 3A
Power 55.4kW 75 hp

Performances

Lifting height 5.85 m 19’2″
Lifting capacity 2500 kg 5500 lb
Drawbar pull 3550 dan 7980 lbf
Breakout force 3427 dan 7704 lbf
Moving speed 25 kmh 15.5 mph
Lifting time (unladen) 8 s
Lowering time (unladen) 5.4 s
Boom extension time (unladen) 5.6 s
Boom retraction time (unladen) 4.3 s
Crowd 3.5 s
Dump 3.6 s

Dimensions

Length (up to the back of the fork) 3.89 m 12’9″
Width 1.81 m 5’11”
Height 1.92 m 6’4″
Weight (unladen) 4710 kg 10362 lb
Turning radius 3.31 m 10’10”
Ground clearance 0.33 m 1’1″

Engine / Battery

Energy Diesel
Engine brand Kubota
Engine type 3A
Power 75 cv 75 hp
Power 55.4 KW
Max. Torque @ Rotation 265 Nm @ tr/min
Number of cylinders 4
Total capacity 3331 cm3
Injection Direct
Cooling Water
Transmission type Hydrostatic

Hydraulic

Flow 88 l/min
Pressure 235 bars
Hydraulic oil tank volume 115 l 30.37 gal

Other specifications

Driving type Seated
Number of wheels 4
Number of wheels (front) 2
Number of wheels (rear) 2
Number of drive wheels (front) 2
Number of drive wheels (rear) 2
Tyre dimensions (front) 12-16.5 12PR SKS CL TUBELESS
Tyre dimensions (rear) 12-16.5 12PR SKS CL TUBELESS
Driving position noise levels 75 dB
Environmental noise levels 104 dB
Vibrations affecting hands/arms <2.5 m/s
